Typically, engineering consulting firms have been designing substations using two-dimensional computer aided design software (CAD) since the 1970s. This common technique produces two-dimensional drawings that are completed individually by designers. Any change to the design requires the designer to incorporate the change in each individual drawing manually. This process becomes an inefficient design practice as it increases the potential for error due to duplicated information appearing across multiple drawings. Accuracy is especially critical in the...
